Form Factor |
1U Rackmount Chassis |
|
M/B Form Factor |
Motherboard MAX 9.6"x9.6". Customer Specified (OEM Available) |
|
Dimensions (Dx Wx H) |
420 x 437.5 x 44(mm) |
|
Material |
High quality Anti-finger 1.0 mm SGCC& Super ABS ROSHs |
|
Front Control |
1x Power, 1x Reset, I/O Ports(Front) |
|
Indicators |
1x Power Led, 1x HDD Led |
|
Hotswap Backplane |
6GB SATA Backplane; |
|
Drive Bays |
External 2.5"：2 |
|
Cooling Fans |
3 x4028mm fans (Rear); |
|
Expansion Slots |
1x Full Height （Front） |
|
PSU Form Factor |
1U Single PSU(250W~600W); / |
|
Color |
Customized) |
|
Application |
Firewall Server,Enterprise Control Server etc. |
|
Net Weight |
4.5Kg |
|
Gross Weight |
5.5Kgs |
|
Unit Carton Size |
535*525*135mm |
|
Customized |
Available |
| Option Item | Part Number | Description |
|---|---|---|
| Slide Rail | TR101 | 2Section Rack Sliding Rails |
| Power Supply A | Flex 1U | 1U Flex 250W, 80 Plus Bronze 1U Flex 300W, 80 Plus Bronze 1U Flex 400W, 80 Plus Gold 1U Flex 600W, 80 Plus Gold |
| Power Supply B | 1U | ENH-1930/1940, 1U 300W/400W, 80 Plus Delta 1U 500W, 80 Plus Gold |
| Power Supply R | 1U Redundant | CRPS 1+1 1U 450W |
| Fan | 4028 | 4*4028BVH-M1F,Becool PWM Dual-Balling 12,000RPM(Default) 4*Delta 40x28mm PWM Dual-Balling 22,000RPM |
| Front Bezel | 1U | Logo Custom |
| Riser Cable | 1U | 1U PCIe x16 or x8 Riser Cable |
| Back I/O Shield Plate | Custom | Rear I/O shield-According M/B |
 |
