Form Factor

IPC3315 OEM

Dimensions (mm)

L412*W430*H132.5mm

Material

Heavy-SGCC 1.2mm Zinc-coated steel

Cooling

2 x 8025Bmm fans (Middle)

Front Panel
Controller

1x Power, 1x Reset,
2x USB3.0

LED Indicators

1x Power Led, 1x HDD Led

Drive Bays

External: 1*5.25“+2*3.5“ Bays
Internal: 1*3.5” Bays

Color

Surface in Black;
OEM etc.

System Board

12”*13”,12”*10.5”,12”*9.6”, 9.6”*9.6”, 17*17cm(ITX) etc.

Expansion Slots

7* Full Height Profile Slot

Power Supply

SFX Powersupply

Package Dimension

565*545*240mm K636K,

Net Weight

9.2Kg

Gross Weight

11.5Kg

Customized

Available

Order Code

M/B

HDD Backplane

PSU

Rear Window

Slide Rail

CS36516M6

12"x13"

16-Bay 2.5"/3.5",6GB mini SAS

Option 600W/750 2U single

650W/800 2U Redundant

7-Slot,FF

Option

CS36516E6

12"x13"

16-Bay 2.5"/3.5", 6GB mini SAS Expander

Option 600W/750 2U single

650W/800 2U Redundant

7-Slot,FF

Option

CS36516G12

12"x13"

16-Bay 2.5"/3.5",12GB mini SAS HD SGPIO

Option 600W/750 2U single

650W/800 2U Redundant

7-Slot,FF

Option

CS36512M6

12"x13"

12-Bay 2.5"/3.5",6GB mini SAS

Option 500W/600 2U single

650W/800 2U Redundant

7-Slot,FF

Option
