Form Factor |
4U Rackmount Chassis |
|
Material: |
Anti-finger Rohs-SGCC 1.0mm
Zinc-coated steel
|
|
Dimensions (Dx Wx H) |
480 x 437.5 x 176.5(mm) |
|
Front Panel
Controller:
|
1x Power, 1x Reset,
2x USB2.0/USB3.0
|
|
LED Indicators:
|
1x Power Led, 1x HDD Led
|
|
Drive Bays :
|
Internal:4*2.5”Bay
|
|
System Board :
|
12”*13”,12”*10.5”,12”*9.6”, 9.6”*9.6
”, 17*17cm(ITX) etc.
|
|
Expansion Slots :
|
8x Full Height;
|
|
Package
Dimension
(W x D x H) • mm
|
630*590*320mm K636K,
G.W:11.2KG / N.W:9.3 KG
|
|
Mounting Kits
|
Option Tooless Rack kits
--- SR-302 /SR-266H
|
|
Customized |
Available |
|
Order Code |
M/B |
HDD Backplane |
PSU |
Rear Window |
Slide Rail |
|
CS36516M6 |
12"x13" |
16-Bay 2.5"/3.5",6GB mini SAS |
Option 600W/750 2U single 650W/800 2U Redundant |
7-Slot,FF |
Option |
|
CS36516E6 |
12"x13" |
16-Bay 2.5"/3.5", 6GB mini SAS Expander |
Option 600W/750 2U single 650W/800 2U Redundant |
7-Slot,FF |
Option |
|
CS36516G12 |
12"x13" |
16-Bay 2.5"/3.5",12GB mini SAS HD SGPIO |
Option 600W/750 2U single 650W/800 2U Redundant |
7-Slot,FF |
Option |
|
CS36512M6 |
12"x13" |
12-Bay 2.5"/3.5",6GB mini SAS |
Option 500W/600 2U single 650W/800 2U Redundant |
7-Slot,FF |
Option |
 |
