CPU Support

Intel® Granit Rapids SP

CPU Socket

FCLGA 4677 / 4710

Screw Type

#8-32

Installation Torque

8 in-lb

Solution

2U Server and Up

Dimensions

118 x 79 x 64.5 mm

Weight

490 ±10 g

Material

5 Heatpipes with Cooper Base and Aluminum Fin Stack

Fan Dimension

60 x 60 x 25 mm

Speed

At Duty Cycle 0~20%: 3000± 200 RPM

At Duty Cycle 50%: 5400± 10% RPM

At Duty Cycle 100%: 11000±10% RPM

Rated Voltage

12V

Bearing

Double Ball

Air Flow

At Duty Cycle 100%: 47.20 CFM

Noise Level

At Duty Cycle 100%: 52.50 dBA

Lead Wire Pin Out

Pin#1-Black(-)
Pin#2- Yellow(+)
Pin#3- Green(Tachometer/ Signal Output)
Pin#4- Blue (PWM)

Thermal Grease

Shin-Etsu X23-8079-2

TDP

400W
